Product kodak

kodak

KODAK FLEXCEL SR Flexographic Plates have been designed to bring brand owners confidence that their packaging will be produced reliably and consistently, and to bring printers of packaging materials increased productivity and peace of mind. FLEXCEL SR Plates are part of Kodak’s complete range of quality products for the packaging industry.
FLEXCEL SR Plates are optimized uniquely for exposure with KODAK PREMIER PR7M Recording Film to provide high resolution and uniformity for ganged images on a single sheet of film.
images
Available in three durometers for a wide variety of applications.
KODAK FLEXCEL SRH Flexographic Plates are premium, high-durometer plates developed specifically for the most challenging jobs that have fine halftone line screen reproduction and solid printing requirements.KODAK FLEXCEL SRM Flexographic Plates are premium, mid-range durometer plates, designed for fine halftone line screen reproduction and solid printing requirements, specifically developed to print on the widest variety of substrates, from tissue to flexible film.
KODAK FLEXCEL SRC Flexographic Plates offer superior performance and mounting properties, making them ideal plates for halftone reproduction on coarse board.
  • Resilience for ever higher press speeds
  • Sharp detail (through hard durometer)
  • Excellent highlight dot formation and integrity with steep shoulders, uniform thickness, and uniform ink transfer coefficient
  • Reliability in supply and performance
  • Consistency between plates and throughout the run
Plate SRH SRM SRC
Plate thickness 1.14 mm / 0.045 in
1.70 mm / 0.067 in
2.28 mm / 0.090 in
2.54 mm / 0.100 in
2.72 mm / 0.107 in
2.84 mm / 0.112 in		 1.14 mm / 0.045 in
1.70 mm / 0.067 in
2.28 mm / 0.090 in
2.54 mm / 0.100 in
2.72 mm / 0.107 in
2.84 mm / 0.112 in 		2.84 mm / 0.112 in
3.18 mm / 0.125 in
3.94 mm / 0.155 in
4.32 mm / 0.170 in
4.70 mm / 0.185 in
5.00 mm / 0.197 in
5.50 mm / 0.217 in
6.00 mm / 0.236 in
6.35 mm / 0.250 in
7.00 mm / 0.276 in
Resolution 1 to 95% @ 150 lpi 1 to 95% @ 150 lpi 3 to 95% @ 133 lpi
Isolated dot reproduction 100 – 130 μm 100 – 130 μm 150 – 200 μm
Fine line reproduction 70 – 100 μm 70 – 100 μm 100 μm
Plate hardness
Shore A		 SRH 1.14 mm: 73
SRH 1.70 mm: 64
SRH 2.28 mm: 62
SRH 2.54 mm: 60
SRH 2.72 mm: 60
SRH 2.84 mm: 59		 SRM 1.14 mm: 70
SRM 1.70 mm: 60
SRM 2.28 mm: 57
SRM 2.54 mm: 54
SRM 2.72 mm: 53
SRM 2.84 mm: 53		 SRC 2.84 mm: 39
SRC 3.18 mm: 37
SRC 3.94 mm: 35
SRC 4.32 mm: 37
SRC 4.70 mm: 37
SRC 5.00 mm: 36
SRC 5.50 mm: 36
SRC 6.00 mm: 36
SRC 6.35 mm: 36
SRC 7.00 mm: 35
Wash-out solution Compatible with most wash-out solvents
Recommended wash-out solvent temperature 20 – 35oC (68 – 95oF)
Ink compatibility Aqueous, solvent-based, UV-cured and cationic inks
Storage and handling Unopened plate packs should be stored flat and away from excessive cold, heat and humidity. Use in a controlled environment of 10 – 25oC (50 – 77oF) and 40 – 55% RH.

SRM

SRC

SRH
